Efficient coding, smarter savings. Upgrade to our bulk ink delivery system. Ideal solution for medium to high-volume production lines.
Low Cost of Print and Total Cost of Ownership (TCO)
Maintenance-free
Ease of Use & Clean
Easy Integration
| Specification | Details |
|---|---|
| Controller | |
| Display | Optional 7" or 10" HMI with Anti-theft Lock |
| Message Design | 1) Simple Message Editor 2) Advanced Message Editor |
| Message Capacity | Unlimited (within HMI/Windows) |
| Start & Stop Time | Immediate |
| Password Protection | Yes |
| Alarm | Built in beacon, 128*64 pixel OLED, Buzzer |
| Number of Printhead | 1 |
| System Language | German, French, Japanese, Portuguese, Spanish, Thai, Turkish, Hindi, Arabic, Mandarin (other languages upon request) |
| Product Certification | CE |
| Connections & Integration | |
| Connectivity | Easy connectivity based on customer needs: Wi Fi (Direct and Access Point connections), Isolated RS232, USB Cable |
| Power Supply | 110 to 220 VAC |
| Encoder | Optional |
| Two or Three Color External Beacon | Optional |
| External Sensor | Yes |
| Mounting & Stand | Stainless Steel T-bracket mounting or Tripod Stand |
| Ink Solution | |
| Technology | Funai Cartridge, MapleJet Advanced Ink System (AIS) |
| Ink Type | Porous & non-porous ink |
| Colour | Black (solvent-based & water-based ink) |
| Cartridge Dimension | 60mm x 74mm x 25.5mm |
| Throw Distance | Hx Ultro TIJ-HR 600dpi up to 4mm Hx Ultro TIJ-HT 300dpi up to 10mm |
| Physical Specifications | |
| Housing Materials | Coloured Anodized Aluminum & Stainless Steel |
| Controller Weight | 1050gm |
| Dimension | 146 mm x 90 mm x 84 mm |
| Environmental Conditions | Temperature 0-50°C, Humidity 0-80% |
| Printing Features | |
| Resolution Maximum | Hx Ultro TIJ-HR 600dpi Hx Ultro TIJ-HT 300dpi |
| Print Speed | 240m/min at 80dpi |
| Logo Printing Option | Yes |
| Barcode Printing | All types of barcodes including QR Codes |
| Number of Print Lines | up to 6 (2mm each line for 1/2" Head) up to 12 (2mm each line for 1" Head) |
| Fonts | All Windows Fonts |
| Height Range of Printable Characters | up to 12.7mm (~0.5") up to 25mm (1") |
| Date Format | Variety of date format |
| Counters | Print counter, message counter, and user-defined counter |
| Message Components | Text | Date | Time | Logo | Counter | Shift | Barcode | External Data | Lot Number | Alphanumeric |
| Advanced Features | |
| Auto Notify | Automatically sends alerts for key events like low ink levels, print job completion, or online data received through selected channels such as USB, RS232, or Wi-Fi (HTTP)—keeping your team informed in real time. |
| Auto Pilot | Allows other external device to control and monitor Hx Printer. Any third party device (e.g. PLC), system, or software can send a command to Hx Printer. |
| Daily Production Report | Provides an hourly print report of the printer giving an overview of the complete daily production |
| Economy Mode | Reduces ink consumption to up to 50% increasing print quantity |
| External Data | Easy integration to external devices e.g. PLC, weighing scale, etc for printing variable data. |
| Ink Estimation Calculator | Provides an estimate number of prints per cartridge based on the message and other parameters |
| Printer Health Check | Detects warning/s to avoid future or unwanted downtime |
| Rollover Time | Easily customise time and date as to company's required production time or work shift |
| Interlock Signal Connection | Easily connect the Hx Ultro TIJ to your host machine to send real-time output signals—such as Fault, Busy (Printing), and Ready status. |
Advanced capabilities for every industrial printing need
Industry-leading print speeds and throughput designed for demanding production environments with zero downtime.
High-resolution output for crisp text, barcodes, QR codes, and graphics ensuring clear, durable identification on any substrate.
Intuitive touchscreen controls with easy message creation, editing, and device management for quick setup and operation.
Engineered for minimal downtime with easy-to-replace consumables, self-cleaning systems, and robust industrial-grade components.
Multiple connectivity options including PLC, RS232, RS485, Ethernet and USB for easy integration into any production line.
Built to withstand harsh industrial environments with IP-rated enclosures, temperature resilience, and dust-proof designs.
Carton
Paper
Film
Foils
Plastics
